MRCS Part B Questions

MRCS Part B Revision · Anatomy

Stomach — MRCS Part B Anatomy

By Dr Richard Miller, MBChB FRCS · Reviewed

Stomach is a surgical anatomy station. Three of the seventeen examined stations in the MRCS Part B OSCE are surgical anatomy. The anatomy stations put a prosected specimen, a model or an image in front of you and ask you to identify structures and say what they do, what they relate to and what happens when they are injured.

What you need to know for the Stomach station

The stomach and its blood supply dissected, with the questions the examiners want: its parts, its nerves, what a gastrectomy takes and what a vagotomy did.

Parts

The cardia around the oesophageal opening; the fundus above the level of that opening, under the left dome of the diaphragm, where swallowed air collects; the body; the pyloric antrum, the pyloric canal and the pylorus itself, a thick ring of circular muscle at the transpyloric plane. The lesser curvature faces up and to the right with the lesser omentum attached, and the angular notch on it marks where the body ends; the greater curvature faces down and to the left and carries the greater omentum and the gastrosplenic ligament.

Blood supply

All from the coeliac trunk. Along the lesser curve run the left gastric artery, from the trunk itself, and the right gastric from the common hepatic; along the greater curve the left gastro-epiploic from the splenic and the right gastro-epiploic from the gastroduodenal, meeting in the omentum; and the short gastric arteries from the splenic supply the fundus through the gastrosplenic ligament. The veins follow the arteries into the portal system, the left gastric vein carrying the oesophageal anastomosis that becomes varices. The gastroduodenal artery runs behind the first part of the duodenum and is the vessel that a posterior ulcer erodes.

Innervation

Parasympathetic from the vagus: the anterior vagal trunk, mostly from the left vagus, runs down the front of the lesser curve giving hepatic and pyloric branches and the anterior nerve of Latarjet; the posterior trunk, mostly from the right, gives a coeliac branch and the posterior nerve of Latarjet. They drive acid and pepsin secretion and motility. Sympathetic fibres from T6 to T9 reach the stomach through the greater splanchnic nerves and the coeliac plexus, carrying the pain of a gastric ulcer to the epigastrium.

Gastrectomy

A distal (subtotal) gastrectomy for an antral tumour, reconstructed as a Billroth I to the duodenum or Billroth II or Roux-en-Y to the jejunum; a total gastrectomy for a proximal or diffuse tumour, with a Roux-en-Y oesophagojejunostomy; a proximal gastrectomy, rarely used; and a sleeve gastrectomy, which removes the greater curve for weight loss. The D2 dissection takes the nodes along the named arteries with the specimen.

Vagotomy

Cutting the vagal supply removes the cephalic stimulus to acid secretion, so ulcers healed, but a truncal vagotomy also paralysed the antrum and pylorus, so it needed a drainage procedure — a pyloroplasty or gastro-enterostomy — and it gave diarrhoea, gallstones and dumping. A highly selective vagotomy divided only the branches to the acid-secreting body and fundus and kept the nerves of Latarjet to the antrum, so the stomach still emptied. Proton pump inhibitors and eradication of Helicobacter made the operation obsolete.

Dumping

Early dumping, within half an hour of a meal, is the hypertonic contents of a stomach without a pylorus flooding the jejunum, drawing fluid into the bowel: bloating, cramps, diarrhoea, and faintness from the fall in circulating volume. Late dumping, two or three hours later, is reactive hypoglycaemia from the surge of insulin that the rapid glucose load provoked. Small dry meals, low in sugar, are the treatment.

The mucosa

It secretes acid and intrinsic factor from the parietal cells, pepsinogen from the chief cells, gastrin from the G cells of the antrum, and the mucus and bicarbonate that protect it from its own acid; it also absorbs alcohol, water and some drugs. The rugae let it stretch, and its epithelium renews itself every few days.

Images from this station

Stomach — MRCS Part B Anatomy
Stomach — MRCS Part B Anatomy
Stomach — MRCS Part B Anatomy

What are you asked at the Stomach station?

The station runs to 14 questions over nine minutes. A prompt the station repeats — against each marker on a specimen, for instance — is listed once here; the model answers are in the question bank.

  1. Identify vessels 1-3
  2. Identify vessels 4-7
  3. Identify vessels 8-13
  4. Identify Structure 14
  5. Identify areas 15-19
  6. Identify areas 20-22
  7. What is structure 23?
  8. Describe the innervation of the stomach
  9. What is the role of gastric mucosa?
  10. What types of gastrectomy do you know?
  11. Prior to the introduction of proton pump inhibitors operations to denervate the stomach helped alleviate ulceration. What would be the effects of interrupting the vagus nerve supply to the stomach?
  12. What is gastric dumping?

And 1 more at this station.

How is the anatomy station marked in MRCS Part B?

An anatomy station is marked out of 20, and all 20 marks go to clinical knowledge and its application. No communication, technical-skill or professionalism marks are available in an anatomy bay, which is unusual: in most other stations more than half the marks sit outside your factual knowledge.

FAQ

What does the Stomach station ask?

It opens with "Identify vessels 1-3" and runs to 14 questions over nine minutes. An anatomy station is marked out of 20, and all 20 marks go to clinical knowledge and its application. No communication, technical-skill or professionalism marks are available in an anatomy bay, which is unusual: in most other stations more than half the marks sit outside your factual knowledge.

How many anatomy stations are there in MRCS Part B?

Three of the seventeen examined stations are surgical anatomy, and two more are surgical pathology. Together they make up the five Anatomy and surgical pathology stations of the Applied Knowledge component.

How are the anatomy stations marked?

Each station is marked out of 20 and all 20 marks are awarded for clinical knowledge and its application. You also receive a separate global rating of pass, borderline or fail for the station.

Are the specimens real?

Yes. Anatomy bays use prosected cadaveric specimens, models and images. Candidates report being shown photographs of specimens as well as the specimens themselves, so practise on real dissection photography rather than diagrams alone.

What happens if I get an early question wrong?

The intercollegiate guidance says that if a wrong answer would affect your performance on later questions at the same station, the examiner gives you the correct answer before moving on. One mistake does not have to cost you the whole bay.

How many stations are in the MRCS Part B OSCE?

Seventeen examined stations of nine minutes each, with a minute to read the task before each one. Two preparation stations and at least one rest station bring the circuit to about twenty, and the exam takes about three and a half hours.

What is the pass mark for MRCS Part B?

There is no published pass mark. The cut score is set separately for Applied Knowledge and Applied Skills, for each circuit, by borderline regression. Published pass rates across the 2024/25 diets ranged from 51% to 66%.

Can I fail a station and still pass?

Yes. There is no rule about how many stations you may fail: the cut score applies to your total mark in each component, so a weak station costs the marks you lost on it and strong stations elsewhere can make them back. Applied Knowledge and Applied Skills are passed separately and must both be passed at the same sitting, so a strong anatomy performance cannot rescue a weak communication one.

Dr Richard Miller, MBChB FRCS

Station summaries are reviewed against the current intercollegiate MRCS syllabus and the published marking blueprint. Guidance changes between diets: check the royal colleges' own pages before relying on a date, a fee or a threshold.
